OUR PRODUCTS
Open well Submersible Pumps
GRAOCH sue mono series single phase horizontal submersible pumps are designed under water tank to over head tank
-
PVC Insulated 3 core 1.5 mm motor cable
-
winding overhang protector
-
locally rewindble and repairable
-
supplied with l bend stainer & cable joining kit
Application
Gardening
Fountain
Farms
Sump to over head tank filling
| Power | Total Head in Meters | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6 | 9 | 12 | 15 | 18 | 21 | 24 | 27 | 30 | 33 | 36 | 39 | 42 | 45 | 48 | 51 | ||||
| S.No | Model | HP/KW | Pipe Size | Discharge in LPM | |||||||||||||||
| 1 | SUB-MONO-0.5 | 0.5/3.5 | 25x25 | 130 | 107 | 85 | 62 | 40 | |||||||||||
| 2 | SUB-MONO-1.0 | 1/0.75 | 25x25 | 60 | 147 | 133 | 120 | 93 | 80 | ||||||||||
| 3 | SUB-MONO-D-1.5 | 1.5/1.1 | 32 x 25 | 160 | 127 | 104 | 93 | 85 | 79 | 74 | 70 | ||||||||
| 4 | SUB-MONO D-2.0 | 2/1.5 | 32X25 | 155 | 131 | 120 | 97 | 86 | 73 | 70 | 65 | 60 | 50 | ||||||
